DN600 Medium Size Hydraulic Top Press Valve Test Bench

This DN600 Medium Size Hydraulic Top Press Valve Test Bench adopts stable integrated bed frame structure and synchronous hydraulic jacking clamping system, the horizontal guide stroke can be adjusted freely to adapt to gate valves, ball valves and other mainstream medium-sized valves with different body lengths. It can complete long-time pressure holding leakage inspection for shell strength and sealing performance, equipped with precision pressure instruments, automatic constant pressure control system and hydraulic overload protection device, supporting free switching of water and air test media.

Balancing load capacity, floor space and comprehensive procurement & operation cost, the bench is specially designed for standardized quality inspection procedures on medium valve production lines. The synchronous double hydraulic cylinder axial clamping structure provides uniform jacking force to avoid flange offset during long pressure holding; independent liquid and gas pressure regulating pipelines realize separate control of shell hydrostatic test and air tightness test pressure, with automatic pressure compensation function to keep test pressure stable.

 The integrated electrical control cabinet is equipped with multi-group shock-resistant pressure gauges and independent operation buttons, with simple operation and low daily maintenance difficulty. The thickened welded base effectively resists deformation under continuous medium load, and reserved PLC digital upgrade interface supports automatic test timing, pressure curve storage and electronic report export. We can provide full CE safety transformation and multi-language operation panel for overseas medium valve assembly factories and energy EPC workshops. If you need cost-effective horizontal axial jacking pressure testing equipment for DN50-DN600 medium valve batch offline inspection, contact our technical team to obtain full parameter sheet and long-term framework quotation within 24 working hours.

Seven Core Differentiated Product Advantages

1.Synchronous Double Cylinder Uniform Force Horizontal Jacking Clamping The core structural advantage of DN600 Medium Size Hydraulic Top Press Valve Test Bench: two hydraulic cylinders run synchronously to output balanced axial clamping force, no unilateral pressure deviation when clamping medium alloy steel valves, stable sealing positioning during long-time pressure holding, effectively avoiding inaccurate detection caused by valve displacement.

2.Wide-range Freely Adjustable Horizontal Guide Stroke Long horizontal integral guide rail, the clamping opening distance can be adjusted steplessly to fit short-body small-bore and long-body DN600 medium valves, one machine covers DN50~DN600 full medium valve specifications, reducing multiple equipment procurement investment for valve manufacturers, another core practical highlight of DN600 Medium Size Hydraulic Top Press Valve Test Bench.

3.Dual Water & Air Independent Medium Switchable Test System Built-in separate water injection booster pipeline and air intake pressure pipeline, matched with independent precision pressure gauges and pressure regulating valves, can independently complete shell water strength test and seat air tightness test, fully meet multi-medium multi-stage pressure holding inspection clauses of API 598 standard.

4.Compact Integrated Stable Welded Bed Frame Integral thick steel plate welded one-piece bed frame, small floor occupation compared with large-bore test benches, stable structure without vibration during continuous batch operation, suitable for medium-sized valve factories with limited workshop space.

5.Built-in Hydraulic Overpressure Automatic Protection Device Independent overflow protection circuit for hydraulic jacking system, automatically release pressure when clamping force exceeds set threshold, prevent valve flange deformation and equipment structural damage caused by over-clamping, meet EU CE industrial mechanical safety standards.

6.Simple Manual Centralized Control System with Low Operation Threshold Concentrated independent button operation panel, separate control of clamping, water boosting, air boosting and pressure relief functions, workers can complete the whole test process without complicated parameter setting, greatly reducing training cost for new operators.

7.Modular Intelligent Digital Upgrade Expansion Interface The central electrical cabinet reserves data communication expansion port, customers can later retrofit touch screen PLC automatic timing pressure holding, real-time pressure curve recording and batch electronic inspection report export function, realizing full digital traceability of production inspection data.

Complete Technical Parameter Table

Seven Target Matching Application Scenarios

1.Medium-sized Valve Mass Production Factories: Batch offline quality inspection of DN50-DN600 gate valves, ball valves before delivery, completing shell strength and long-time tightness pressure holding test.

2.Petrochemical & Natural Gas Pipeline Component Manufacturers: Batch pressure inspection of medium-sized pipeline cut-off valves, supporting pre-commissioning inspection for medium-scale energy EPC projects.

3.Municipal Water Supply & Sewage Engineering Workshops: Strength and air tightness test of medium-pressure cast iron flanged valves for urban water conservancy supporting projects.

4.Thermal Power Plant Auxiliary Equipment Processing Workshops: Periodic pressure recheck of medium-bore auxiliary control valves for power station circulating water and heating pipelines.

5.Independent Medium Valve Maintenance Service Stations: Re-inspection of recovered medium valves after sealing surface repair and refurbishment.

6.Overseas Medium-scale Valve Assembly EPC Workshops: Compact space-saving medium-bore testing equipment, matching multi-language operation panel and complete set of CE export certification documents.

7.Valve Sealing Material R&D Labs: Contrast pressure holding leakage test of new medium-sized valve sealing structures under different pressure grades.

Global Pre-sale, In-sale & After-sales Integrated Service System

Pre-sales Technical Customization Support

Professional medium valve inspection process engineers conduct one-on-one technical communication, confirm valve nominal diameter range, maximum test pressure, required inspection standards and workshop space layout, provide equipment placement layout drawing and free sample pressure holding test verification service, issue targeted cost-effective complete test solution and formal quotation within 24 hours.

In-sales Production & Export Shipment Service

Whole-process real-time video tracking of production progress, full load continuous pressure cycle test before factory delivery with original test record report retained; export version adopts thickened plywood shockproof and moisture-proof reinforced packaging, complete hydraulic schematic diagram, electrical wiring diagram, multilingual operation manual and full set of customs clearance certification documents delivered together with machine.

After-sales Global Technical Quality Guarantee

Synchronous hydraulic jacking cylinders, precision pressure gauges, PLC electrical core components enjoy 24-month global warranty, free supply of non-human damage replacement parts within warranty period; provide remote online PLC parameter debugging, complete pressure test operation video tutorial, coordinate overseas local agents to provide on-site maintenance service; lifelong supply of general hydraulic spare parts, free long-term medium valve pressure testing process technical consultation.

FAQ & Official Purchase Guidance

Frequently Asked Questions

Q1: Can this bench complete long-time water & air dual medium pressure holding inspection required by API 598 standard?

A1: Yes, independent water and air pressure regulating pipelines are equipped, with automatic constant pressure compensation system, fully matching all long-time pressure holding and medium switching inspection clauses of API 598 standard for DN50-DN600 medium valves.

Q2: Does the synchronous double cylinder clamping structure cause flange offset during long pressure holding?

A2: Two hydraulic cylinders operate synchronously to output balanced uniform axial jacking force, the horizontal guide rail ensures coaxiality of valve clamping, no displacement or offset even after several hours of continuous pressure holding.

Q3: Can automatic timing and pressure curve storage function be upgraded after equipment purchase?

A3: The control system reserves data expansion interface at factory, customers can retrofit touch screen PLC automatic timing pressure holding and electronic report export function at any time in later use.

Q4: Can the machine carry out full CE safety standard transformation for overseas export?

A4: We can complete all CE industrial machinery safety transformation according to overseas market requirements, configure multi-language touch screen panel and 415V export voltage, provide complete CE certification document set for customs clearance and overseas project acceptance audit.

Q5: What is the standard production delivery cycle?

A5: Standard DN600 Medium Size Hydraulic Top Press Valve Test Bench delivery cycle is 30 working days; customized long stroke, high pressure and digital upgraded model delivery cycle is 35 working days.

Purchase Guidance

Please send detailed information including valve nominal diameter range, maximum test pressure, execution inspection standard, daily batch inspection quantity and export voltage/certification demand to our engineering team mailbox. Our technical team will generate complete integrated medium-bore horizontal axial jacking valve pressure inspection solution and long-term bulk procurement preferential quotation within 24 working hours, support annual framework cooperation orders for medium-sized valve factories and medium-scale global energy pipeline EPC supporting project orders.
