Split Water Tank Valve Tester, Horizontal Valve Test Bench, Valve Hydrostatic Test Machine, Underwater Bubble Leak Detector, Flange Valve Air Tightness Tester
Model:
DN100 Split Water Tank Horizontal Valve Test BenchDN100 Split Water Tank Horizontal Valve Test Bench:
DN100 Split Water Tank Horizontal Valve Test BenchTest Method:
Underwater bubble leakage inspectionApplicable Valve:
Flange connected industrial valvesCore System:
High pressure booster, pressure gauge and sensorTest Function:
Hydrostatic shell strength test, low pressure air tightness testClamping Mode:
Horizontal axial clampingOperation Feature:
Set test pressure and pressure holding time freelyApplication:
Valve factory inspection, valve maintenance recheckThis Split Water Tank Horizontal Valve Test Bench is specially designed for shell hydrostatic strength test and seat air tightness submerged bubble inspection of flanged straight-through valves, fully complying with GB/T13927 and API 598 international valve testing standards. It is equipped with independent high-pressure boosting system, multi-group precision pressure gauges and pressure transmitters, plus automatic constant pressure holding control module; users can freely set test pressure and pressure holding duration according to different valve pressure classes. The horizontal clamping structure supports horizontal placement of medium & large-sized valves, eliminating the safety risk of lifting heavy valves for vertical test benches.
After clamping the valve, operators can push the workpiece into the independent diving water tank, directly observe bubble overflow to judge sealing leakage status, with intuitive and reliable test results, effectively avoiding missed leak detection caused by indirect pressure data judgment. The split water tank can be placed separately beside the main control cabinet, suitable for workshops with limited installation space; the tank body adopts thickened anti-rust steel plate welding, with drainage port for easy daily sewage cleaning. The main control cabinet integrates all pressure regulation, boosting and electrical operation modules, with independent sealed cabinet door to protect hydraulic and electrical components from water vapor corrosion.
The equipment covers DN15~DN100 standard flanged ball, gate and globe valves, supporting two testing media of water and air. It reserves touch screen digital upgrade interface for automatic pressure curve recording and test report export; we can provide full CE safety transformation and multi-language operation panel for overseas valve factories and energy EPC inspection workshops. If you need split-type visual submerged bubble valve pressure testing equipment for factory delivery inspection and maintenance recheck, contact our technical team to obtain complete parameter sheet and long-term framework quotation within 24 working hours.


1.Split Independent Main Machine & Diving Water Tank Layout The landmark structural feature of YFJX-LQ DN100 Split Water Tank Horizontal Valve Test Bench: separate control cabinet and water tank can be arranged flexibly according to workshop layout, the water tank can be moved independently without moving the heavy hydraulic main unit, solving the fixed space limitation of integrated test benches, highly adaptable to small and medium valve workshops.
2.Horizontal Side Clamping for Medium & Large Valve Easy Loading Horizontal axial clamping design requires no vertical hoisting of heavy valves, workers only push the valve horizontally to complete positioning and clamping, reducing labor intensity and falling safety hazards; the adjustable clamping stroke matches various length DN15-DN100 flanged valves, one machine covers full conventional specifications, another core practical advantage of YFJX-LQ DN100 Split Water Tank Horizontal Valve Test Bench.
3.Intuitive Submerged Bubble Visual Leakage Detection Whole valve is fully immersed in clean water tank during air tightness test, leakage point will generate continuous air bubbles, inspectors can directly locate tiny sealing gaps which are hard to identify only through pressure fluctuation data, greatly improving the accuracy of low-pressure air tightness inspection.
4.Dual Medium Independent Boosting & Pressure Holding System Separate hydraulic water boosting pipeline and pneumatic air boosting pipeline, equipped with independent pressure regulation valves and precision pressure monitoring gauges, can carry out shell water strength test and seat air tightness test separately, automatically compensate pressure loss during holding period to maintain stable test pressure.
5.Anti-rust Thickened Detachable Diving Water Tank The split water tank is welded with thickened carbon steel plate with anti-corrosion paint inside and outside, equipped with bottom drain valve for quick cleaning of residual water and metal impurities after daily testing; independent tank design avoids water vapor entering the electrical control cabinet to cause circuit short circuit.
6.Multi-layer Overpressure & Water Vapor Safety Protection Built-in hydraulic overpressure relief valve, gas overpressure cut-off valve and cabinet waterproof sealing structure, triple safety interlock to prevent overpressure valve burst and electrical component damp damage, fully meet EU CE industrial mechanical safety standards for export.
7.Reserved Modular Digital Intelligent Upgrade Port The main control electrical system reserves data communication expansion interface, customers can later retrofit touch screen PLC automatic test cycle, pressure curve storage and electronic inspection report export function, realize full digital traceability of inspection data and seamless docking with factory MES intelligent management system.
|
Specification Item |
Standard Configuration Parameter |
|
Full Model Name |
DN100 Split Water Tank Horizontal Valve Test Bench |
|
Applicable Valve Size |
DN15 ~ DN100 Flanged Straight-through Industrial Valves |
|
Layout Form |
Split Type: Independent Control Main Unit + Separate Diving Water Tank |
|
Clamping Mode |
Horizontal Axial Hydraulic Quick Clamping |
|
Test Media Support |
Water (Shell Strength Test) + Air (Submerged Bubble Tightness Test) |
|
Pressure Monitoring |
Multi-group Independent Precision Pressure Gauges + Pressure Transmitters |
|
Max Test Pressure |
Customizable PN16 PN100 / PN160 high pressure version |
|
Control Mode |
Standard Manual Button Control Optional Touch Screen Digital PLC System |
|
Water Tank Structure |
Thickened Anti-rust Welded Tank with Bottom Drain Valve |
|
Safety Protection |
Hydraulic Gas Overpressure Relief + Waterproof Cabinet + Emergency Stop Triple Interlock |
|
Rated Input Voltage |
380V Three-phase Industrial Power, customizable 220V 415V export voltage |
|
Supporting Certification |
ISO9001 Production System, CE Safety Modification Support, API 598 & GB/T13927 Standard Compliance |
|
Minimum Order Quantity |
1 Unit, support sample trial order and annual long-term bulk framework order |
|
Global Warranty Period |
24 Months for hydraulic boosting unit, pressure sensor and core electrical components |
|
Production Origin |
Wenzhou, Zhejiang, China Valve Capital |
1.Medium & Small Valve Manufacturing Factories: Batch offline delivery inspection of DN15-DN100 ball, gate and globe valves, completing shell strength and submerged bubble air tightness full test before delivery.
2.Petrochemical & Natural Gas Pipeline Maintenance Stations: Re-inspection of recovered used pipeline valves after maintenance, visual bubble leak detection to confirm valve sealing performance recovery.
3.Municipal Water Supply & Drainage Engineering Inspection Rooms: Low-pressure cast iron municipal valve tightness testing, project acceptance auxiliary visual leakage inspection.
4.Thermal Power Plant Auxiliary Workshops: Periodic pressure recheck of small-bore auxiliary control valves for heating and circulating water pipelines.
5.Independent Third-party Valve Inspection Labs: Visual leakage verification for valve samples, pre-inspection before official API standard certification test.
6.Overseas Small Valve Assembly EPC Workshops: Split compact layout saves factory space, matching multi-language panel and full set of CE export certification documents.
7.Valve R&D Sealing Performance Labs: Contrast leakage test of new sealing structure prototypes, intuitive recording of tiny leak point distribution under different pressure grades.
Professional valve inspection engineers conduct one-on-one communication, confirm valve nominal diameter range, maximum test pressure, required inspection standards and workshop space layout, provide equipment placement layout drawing and free sample submerged bubble test verification service, issue targeted cost-effective complete test solution and formal quotation within 24 hours.
Whole-process real-time video tracking of production progress, full pressure cycle test before factory delivery with original test record report retained; export version adopts thickened plywood shockproof and moisture-proof reinforced packaging, complete hydraulic schematic, electrical wiring diagram, multilingual operation manual and full set of customs clearance certification documents delivered together with machine.
Hydraulic boosting unit, pressure sensor, PLC electrical core components enjoy 24-month global warranty, free supply of non-human damage replacement parts within warranty period; provide remote online PLC parameter debugging, complete submerged bubble test operation video tutorial, coordinate overseas local agents to provide on-site maintenance service; lifelong supply of general hydraulic spare parts, free long-term valve pressure testing process technical consultation.
Q1: Can this bench complete submerged bubble air tightness test required by API 598 standard?
A1: Yes, the split independent diving water tank realizes full valve immersion, matching dual water-air boosting system, fully meets API 598 low-pressure submerged bubble leakage inspection clauses.
Q2: Is the split water tank easy to move and clean?
A2: The water tank is an independent separate component without heavy hydraulic accessories, can be pushed freely in the workshop; bottom drain valve realizes rapid drainage and impurity cleaning, daily maintenance is simple and time-saving.
Q3: Can digital automatic test function be upgraded after equipment purchase?
A3: The control system reserves data expansion interface at factory, customers can retrofit touch screen PLC automatic pressure holding, pressure curve recording and electronic test report export function at any time in later use.
Q4: Can the machine carry out full CE safety standard transformation for overseas export?
A4: We can complete all CE industrial machinery safety transformation according to overseas market requirements, configure multi-language touch screen panel and 415V export voltage, provide complete CE certification document set for customs clearance and overseas project acceptance audit.
Q5: What is the standard production delivery cycle?
A5: Standard YFJX-LQ DN100 Split Water Tank Horizontal Valve Test Bench delivery cycle is 30 working days; customized high-pressure version and digital upgraded model delivery cycle is 35~40 working days.
Please send detailed information including valve nominal diameter range, maximum test pressure, execution inspection standard, daily inspection quantity and export voltage/certification demand to our engineering team mailbox. Our Wenzhou Yufeng valve test bench manufacturer technical team will generate complete integrated split diving tank valve pressure inspection solution and long-term bulk procurement preferential quotation within 24 working hours, support annual framework cooperation orders for medium and small valve factories and global energy pipeline EPC supporting project orders.
